8 Digits Counter

This is an 8-digit Counter based on Microcontroller

Main Features of Unit:-

• INPUT: Potential free contact/Proximity Switch: PNP or NPN
• DISPLAY: 8-digit 7-Segment Red LED Display. 0.56”

Features of the Counter:

• Non-resetable 8-digit counter saved in NVRAM.
• All parameters are stored in non-volatile ram.
• Reset: Through Front Key or remote input
• Counting: Up/Down programmable
• Front Reset: Enable/disable thro’ Keyboard or lock on back panel
• Preset: Enable/Disable thro’ Keypad
• KEYPAD: Four Keys Membrane Keypad
• POWER SUPPLY: 115V/230V AC (Field selectable)/12-24 VDC
• OPTIONS:
  • One Preset Relay
  • Serial: RS232 or RS485
• ENCLOSURE: Metalised DIN Standard (General Purpose)
• Panel Mounting type
  • DIMENSIONS: OUTER: 144 mm (W) X 72 mm (H) X 160 mm (D)
