General Specifications:
- No. of Streams: up to 4
- Operating Voltage: 110-230 VAC +/- 10%, 1 Phase, 50 Hz Nominal
- Key board: 12 keys keypad
- Display: 20 Character x 4 Line LCD with back lit
- Relays: Stream selection: 4 Relays 1 C/O type
- Relay Contact rating: 2A/250 AC, Resistive for each relay
- Stream selection logic: time based and/or external input triggered
- Digital Inputs: 1 (Potential free)
- Analog Inputs: 1 channels, 4 to 20 mA
- Analog Output: 4 Channels, 4 to 20 mA, S/H type
- Dimension:
- Outer: 192 (W) x 96 (H) x 160 mm (D)
- Cutout: 186 (W) x 92 mm (H)
- Enclosure: DIN standard, General purpose, Metallic, Panel Mount
