Stream Selector SS1414

This is a popular Microcontroller base unit. It is designed to get data from field devices on RS-232/485 serial (ASCII/MODBUS) interface. Data received from field devices on serial port is transmitted as analog signal for individual channels (Up to six).

Specification :

• Operating Voltage: 24VDC +/- 10%
• Power rating < 20 VA
• Key board: 12 keys keypad
• Display: 20 Character x 4 Line LCD with back lit
• 32 Discrete LEDs for process status Indication
• Communication Interface: RS-232/485 (ASCII/MODBUS)
• Alarm Relays (Optional):
  • Up to 6 Relays 1 NO type
    • Common Alarm (Optional): 1 Relay 1 NO type
• Relay Contact rating: 2A/250 AC, Resistive for each relay
• Analog Output: Up to 6 Channels, 4 to 20 mA
• Dimensions:
  • Outer: 244 (W) x 160 (H) x 100 (D), Cutout: 208 (W) x 116 (H)
• Weight < 2 Kgs
• Enclosure: General purpose, Made up of SS, Panel Mount
• The unit is also available in other packages:
  • 192 x 96 x 110 mm, Panel mount
  • 84/1U/200 mm rack mounting
